CB10

Compact Battery-Powered Loudspeaker System

Write your review
Contact Us
We're sorry, but this item is unavailable.
Free -Day Shipping
Only Left!
Preorder Today
Coming Soon
Get it  if you order in   Price:
×
Get It Sooner
Get it by when you order within
Call to order!
Find Authorized Dealer
Buy Online
Rent / Buy Local

Battery Powered

Bluetooth® Audio

Lightweight & Portable

10-Inch Woofer; 1-Inch Compression Driver

QSC Loudspeaker
Control App

6-Year Warranty

The CB10 is a compact, battery-powered loudspeaker system offering unrivaled audio performance and versatility. It features a 10-inch LF driver, 1-inch compression driver and 3-channel mixer for microphones, instruments and Bluetooth® streaming. Ideal for DJs, event professionals and musicians, it offers easy plug-and-play operation and customization via the QSC Loudspeaker Control app.

Key Features

PROFESSIONAL PA PERFORMANCE

Powerful, Compact 2-way System

  • 440 watts of peak power (Class D)
  • 10-inch woofer
  • 1-inch HF compression driver
  • 127 dB @ 1 m (peak SPL)

Integrated 3-Channel Mixer
Wireless Remote Control

  • Two combo XLR inputs with independent Factory Presets
  • QSC Loudspeaker Control App (iOS & Android) for convenient system remote control

Room Delay

  • 200 ms (max) of room delay



VERSATILE

Simple to Use

  • Large carry handle on the enclosure top
  • Lightweight and portable
  • 30 degrees tilt back (floor deployment)
  • Integrated pole cup (stand deployment)

Bluetooth® 5.1 Audio

  • For control and audio with True Wireless Stereo (TWS) Bluetooth

Battery and AC Power

  • Up to 12 hours of battery power (rechargeable in approx. 4 hrs)
  • User-installable/removable battery pack
  • AC power for unlimited steady operation


Control your CB10 and all QSC Bluetooth-equipped loudspeakers right from your phone. The Loudspeaker Control app gives you instant access to essential audio controls and advanced capabilities.

Download on the App Store
Get it on Google Play

CB10 Accessories

CB10 Battery
User-replaceable battery for your CB10.

learn more

CB10 Cover
Protect your CB10 with a cover.

learn more

Resources

Model CB10
Configuration Two-way Rechargeable Loudspeaker System
LF Transducer: 254 mm (10-inch), cone
HF Transducer: 25.4 mm (1-inch), compression driver
Frequency Response (-6 dB) 51 Hz - 18 kHz
Frequency Range (-10 dB) 47 Hz - 20 kHz
Nominal Coverage Angle: 90° Axisymetric
Maximum Rated SPL1: 127 dB @ 1 m
Amplification (peak): Class D, 440 W
Cooling: Convection cooling
Backpanel Controls: 3 x Rotary level potentiometers (Gain)
2 x MIC Boost Push-Switch
2 x 6-way Contour Selection Rotary-Switch (featuring CUSTOM APP controls)
1 x Bluetooth Switch
1 x Output Select Switch
1 x AC Power Switch
Loudspeaker Control App Functions: Input Channels: Gain Control, Presets (Channels A and B), EQ
Reverb (Channels A and B )
Ducker (Channel A)
Contour Selection
Custom Output Routing
Footswitch Functionality: Channel Mute, FX Mute, or Channel Boost
Bluetooth Audio Configuration
Loudspeaker Firmware Updates
Backpanel Indicators: 3 × Input Signal/Clip LEDs
2 x MIC selected LEDs
3 x Battery Charge LEDs
1 x Limiter Active LED
1 x Bluetooth LED
1 x Output Select LED
1 x Power/Standby LED
Connectors: 2 × locking XLR/F ¼ inch combo (Line Input and Mic/Line Input)
1 × 3.5 mm TRS (Stereo Input)
1 x 6.3 mm TS (Footswitch)
1 × XLR/M (Mix Output)
1 × locking IEC Power Connector
DC Power (Battery): Rechargeable Lithium-ION 22.2 V, 4400 mAh, 97 Wh Battery Module (1x unit included with CB10)
Battery life: up to 12 hours / Battery charging time: approx. 4 hours
AC Power Input: Universal Power Supply: 100-240 VAC, 50/60 Hz
AC Power Consumption2: 100 VAC, 1A / 120 VAC, 0.9 / 240 VAC, 0.5A
Enclosure Material: Polypropylene
Color: Black (RAL 9011)
Grille: Powder-coated steel with internal lining (18 Gauge)
Loudspeaker Dimensions (H×W×D): 465 x 313 x 287 mm / 18.3 x 12.3 x 11.3 in
Carton Dimensions (H×W×D): 559 x 406 x 381 mm / 22 x 16 x 15 in
Net Weight: 12.2 kg / 26.9 lb
Shipping Weight: 14.5 kg / 32 lb
Battery Chemistry: Lithium Nickel Manganese Cobalt Oxide
Regulatory: CE, WEEE, TUV, China RoHS, RoHS II, FCC Class A
Optional Accessories: CB10-CVR: Weatherized Cover for the CB10 Loudspeaker System
CB10-BATTERY: Rechargeable Lithium-ION 22.2 V, 4400 mAh, 97 Wh Battery Module


1Measured at 1 meter, on-axis, in full space, using IEC268 filtered noise.
21/8 power is representative of current draw with typical music program material with occasional clipping.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
All specifications are subject to change without notice.
